40ft Front Loading Dump Flatbed Semi Trailer

You are here: Home » Trailer&Truck » Flatbed Semi Trailer » 40ft Front Loading Dump Flatbed Semi Trailer

Material:	Please select steel
Axle Number:	Please select 3 axle
Suspension:	Please select Air suspension
Size:	Please select customizable
Availability:

This product is no longer available

Product Description

The vehicle body is made of high-quality steel, advanced technology and strict production technology.The structure of the vehicle is reasonable, reliable, easy to operate and beautiful.All parts are manufactured by famous manufacturers at home and abroad, and they are purchased, inspected and used in strict accordance with the requirements of quality system documents to ensure the good performance of the vehicle.

Brand	LUEN
Maximum load	45T
Length * Width *Height(mm)	1300025501350
Axle	LH 13T American Type Axle *3
Suspension	LH 13T*3 Three-axis Mechanical Suspension
Leaf Spring	thickness * width-number of pieces:13mm* 90mm-10
King Pin	2"/3.5”welding / assembly
Landing Gear	28T linkage 1 single action
Tire /Rim	12.00R22.5 *12
Stringer(工-beam)	Thickness of upper wing: 12mm
	Web thickness: 8mm
	Thickness of lower wing: 14mm
	Height:450mm
Bottom Plate	4mm patterned board / smooth board
The above specifications are optional, and Fuwa/PBW axles can be configured.

Laser cutting machine high speed, high precision cutting

Laser welding fixed-point welding, strong welding force, beautiful welding seam

The suspension is automatically positioned and welded to make it firm

The car plate and the frame are fully matched, calibrated and positioned

Automatic welding, fast speed, beautiful welding seam.Electrophoresis primer and powder spray coating

, the surface is smooth and flat, ensuring uniform color in the later stage, without rust.

Ensure the accurate positioning of the tires and avoid unnecessary problems with the tires

during transportation.The whole semi-trailer is strong and beautiful

Shandong Luen Auto Co., Ltd.

Shandong Luen Auto Co., Ltd. is a professional supplier of semi-trailers committed to improving quality and insisting on the principle of "innovation, quality, professionalism and mutual benefit" to achieve the goal of satisfying customers. Strong technical force, superb manufacturing technology, equipment and professional production team provide a solid backing quality assurance for product innovation, development and production.
